Optional Equipment:
PART NO. DESCRIPTION
50006 Deduct for 15" x 10" 6 - 6" Wheels
800105 Brakes, Two-Wheel Free-Backing Hydraulic Surge (Not Available on GN)
800107 Brakes, Four-Wheel Free Backing Hydraulic Surge (Not Available on GN)
800201 Brakes, Two-Wheel Electric w/ Safety Breakaway Kit
800213 Brakes, Four-Wheel Electric w/ Safety Breakaway Kit
60077 2 5/16" Adj. Ht. Ball Coupler, 20,000 Lbs. Cap., IN LIEU OF CLEVIS
60002 3" Adj. Ht. Lunette Eye, 20,000 Lbs. Capacity, IN LIEU OF CLEVIS
CP000004 3" Adj. Ht. Lunette Eye, IN ADDITION TO CLEVIS
CP000011 2 5/16" Adj. Ht. Ball Coupler, IN ADDITION TO CLEVIS
CP000083 Pintle Hook (Mounts to Truck), 18,000 Lbs. Tongue Weight
800163 Lights, Sealed Beam with 3-Light ID Bar
800141 Hose Stand, Bolt-On
800644 Easy Access Valve Extension Handle
800526 Inductor Stand, Bolt-On, For 15-Gallon Inductor Tank
800559 5' Frame Extension in Front of Tank with 4' L x 58" W x 2" Wood Platform and 12" Tall Railing. Removable Rail on Drivers Side. Includes 10,000 Lb. Drop-Leg Top-Wind Jack
800175 5' Frame Extension in Front of Tank with 4' Long x 71" Wide 2"
Wood Platform and 12" Tall Railing. Removable Rail on Drivers Side.
Includes 10,000 Lb. Drop-Leg Top-Wind Jack
800046 Gooseneck with 2 5/16", Adjustable Height Load Leveler Coupler and
10,000-Lb. Drop Leg Jack. Includes 30" Pump Plate Between Gooseneck
Frame and Front of Tank
60073 16" x 6" x 6-6" IN LIEU OF 15" x 10" x 6-6"
*Cost to Lengthen Frame Per Foot
* Paint Color other than Duo Lift Blue

Optional Equipment:
PART NO. DESCRIPTION (Gooseneck not Available on Ag Trailer)
50015 Deduct for No 22.5" x 8.25" x 8 - 8" Wheels
800078 13" x 2 1/2" Free-Backing Hydraulic Surge Brakes, on 2nd Axle
800651
2-Wheel Electric Brakes In Lieu Of 2-Wheel Hydraulic Surge Brakes (8-Bolt)
800653 4-Wheel Electric Brakes In Lieu Of 4-Wheel Hydraulic Surge Brakes (8-Bolt)
60077
2 5/16" Adj. Ht. Ball Coupler, 20,000 Lbs. Cap., IN LIEU OF CLEVIS
60002 3" Adj. Ht. Lunette Eye, 20,000 Lbs. Capacity, IN LIEU OF CLEVIS
CP000004 3" Adj. Ht. Lunette Eye, IN ADDITION TO CLEVIS
CP000011 2 5/16" Adj. Ht. Ball Coupler, IN ADDITION TO CLEVIS
CP000083 Pintle Hook (Mounts to Truck), 18,000 Lbs. Tongue Weight
800237 Fenders, Steel Walk-On Type with Rear Step
800238 Fenders, Steel Walk-On Type with Rear Step and Handrail
800085 Fenders, 14 Gauage Light-Duty, Not Designed for Carrying Loads
800141 Hose Stand, Bolt-On
800526 Inductor Stand, Bolt-On, For 15-Gallon Inductor Tank
800601 5' Frame Extension in Front of Tank with 4' L x 74" W x 2" Wood Platform
and 12" Tall Railing. Removable Rail on Drivers Side.
Includes 10,000 Lb. Drop-Leg Top-Wind Jack
*Cost to Lengthen Frame Per Foot
*Paint Color other than Duo Lift Blue
*Tire Options: Set of Four, Mounted
UT000013 11:00-22.5 Extra Good Used Truck Tires
